Home /Products/Cable Soldering Machine/Automatic Soldering Machine with Customizable Cutting Length High-Definition Screen and 6 Servo Motors

Automatic Soldering Machine with Customizable Cutting Length High-Definition Screen and 6 Servo Motors

1
MOQ
11000
Price
Automatic Soldering Machine with Customizable Cutting Length High-Definition Screen and 6 Servo Motors
Features Gallery Product Description Chat Now
Features
Specifications
Cutting Length: 20-1000mm (Customizable Beyond Range)
Rear Stripping Length: 1-12mm (Customizable Beyond Range)
Linear Guides: HIWIN (Taiwan)
Cylinders: Airtac (Taiwan)
Twisting Length: 3-12mm (Customizable Beyond Range)
Ribbon Cable: 2P-4P
Motors & Drives: 6 Sets Of Servo Motors & Drives
Front Stripping Length: 1-7mm (Customizable Beyond Range)
Display Screen: High-definition Screen, We-con
Ball Screws: TBI Motion (Taiwan)
Production Capacity: 1×5 Wires, Approx. 5,000 Pcs/hour Ribbon Cable: 2P, 5 Wires: Approx. 4,000 Pcs/hour 3P-4P, 3 Wires: Approx. 2,400 Pcs/hour 6P-12P, 2 Wires: Approx. 1,500 Pcs/hour 8P-24P, 1 Wire: Approx. 700 Pcs/hour
Electronic Wire: 18AWG-32AWG
Pressure: 2 Ton
Tinning Length: 1-12mm (Customizable Beyond Range)
Highlight:

Customizable Cutting Length Automatic Soldering Machine

,

High-Definition Screen Wire Crimping Machine

,

6 Servo Motors Wire Processing Machine
Basic Infomation
Place of Origin: China
Brand Name: JunSheng
Certification: CE /ISO
Model Number: HR-2DSC
Payment & Shipping Terms
Packaging Details: Wooden Box
Delivery Time: Within 5 Working Days
Payment Terms: L/C,D/A,Western Union,T/T,D/P
Supply Ability: 200
Product Description
Easy Operation Cable Harness Tinning Ring Terminal Wire Stripping and Crimping Machine

Easy Operation Cable Harness Tinning Ring Terminal Wire Stripping and Crimping Machine is designed for efficient cable processing with dual-line capability and wide wire compatibility.

Download Technical Specifications
Key Features
  • Dual line processing mode and wide line compatibility - Supports two working specifications: 18AWG-32AWG cable handling and 2P-24P cable handling, covering the most common sizes of thin electronic wires to meet diverse wiring production needs.
  • Adjustable multi size machining parameters - Fully customizable processing dimensions: cutting length can be adjusted between 20mm and 1000mm, front and rear peel length 1-10mm, twist length 3-12mm, tin plating length 1-12mm. Flexible adaptation to different terminal assembly and welding requirements.
  • Efficient production capacity - Stable high hourly output with various configurations.
Production Capacity
Configuration Output (per hour)
1×5 wires Approx. 5,000 pcs/hour
Ribbon Cable - 2P, 5 wires Approx. 4,000 pcs/hour
Ribbon Cable - 3P-4P, 3 wires Approx. 2,400 pcs/hour
Ribbon Cable - 6P-12P, 2 wires Approx. 1,500 pcs/hour
Ribbon Cable - 8P-24P, 1 wire Approx. 700 pcs/hour
Facility & Operations
Shenzhen Junsheng Automation Equipment Company manufacturing workspace and facility Junsheng equipment exhibition and trade show display at industry event Junsheng product packaging and secure shipping process Junsheng quality certification and compliance documentation
