High-definition Screen Wire Harness Processing Machine with 8000 pcs/hour Capacity and Customizable Cutting Length

1
MOQ
5650
Price
High-definition Screen Wire Harness Processing Machine with 8000 pcs/hour Capacity and Customizable Cutting Length
Features Gallery Product Description Chat Now
Features
Specifications
Display Screen: High-definition Screen, Brand: We-con
Linear Guides: Brand: HIWIN (Taiwan)
Production Capacity: 18AWG-32AWG, 8-wire: Approx. 8,000 Pcs/hour14AWG-32AWG, 5-wire: Approx. 5,000 Pcs/hour
Ball Screws: Brand: TBI Motion (Taiwan)
Motors & Drives: 6 Sets Of Servo Motors & Drives
Weight: 300KG
Voltage: 220V
Front Stripping Length: 1-10mm (Customizable Beyond Range)
Rear Stripping Length: 1-10mm (Customizable Beyond Range)
Twisting Length: 3-10mm (Customizable Beyond Range)
Cylinders: Brand: Airtac (Taiwan)
Cutting Length: 20-1000mm (Customizable Beyond Range)
Tinning Length: 1-10mm (Customizable Beyond Range)
Wire Range: 18AWG-32AWG (8-wire);14AWG-32AWG (5-wire)
Wire Processing Modes: 5-wire And 8-wire Simultaneous Processing
Highlight:

8000 pcs/hour Wire Harness Processing Machine

,

Customizable Cutting Length Wire Harness Processing Machine

,

High-definition Screen Automatic Soldering Machine
Basic Infomation
Place of Origin: China
Brand Name: JunSheng
Certification: CE /ISO
Model Number: HR-02DS
Payment & Shipping Terms
Packaging Details: Wooden Box
Delivery Time: Within 5 Working Days
Payment Terms: L/C,D/A,Western Union,T/T,D/P
Supply Ability: 200
Product Description
Multi-function Wire Harness Twisting and Tinning Ring Terminal Wire Cutting Stripping and Crimping Machine

Multi-function Wire Harness Twisting and Tinning Ring Terminal Wire Cutting Stripping and Crimping Machine

Download Technical Specifications
Key Features
  • Dual Wire Processing Modes & Wide Wire Compatibility: Supports 5-wire simultaneous processing for 14AWG-32AWG cables and 8-wire processing for 18AWG-32AWG cables, covering most common thin electronic wire sizes.
  • Adjustable Multi-Size Processing Parameters: Fully customizable dimensions including cutting length (20mm-1000mm), front & rear stripping length (1-10mm), twisting length (3-10mm), and tinning length (1-10mm).
  • High Efficient Production Capacity: Stable output of approximately 5,000 pieces per hour for 5-wire processing and up to 8,000 pieces per hour for 8-wire processing.
Exhibition & Quality Assurance
Junsheng equipment exhibition and trade show display Junsheng product packaging and shipping process Junsheng quality certification and standards
