Production Capacity:
18AWG-32AWG, 8-wire: Approx. 8,000 Pcs/hour14AWG-32AWG, 5-wire: Approx. 5,000 Pcs/hour
Cutting Length:
20-1000mm (Customizable Beyond Range)
Tinning Length:
1-10mm (Customizable Beyond Range)
Ball Screws:
TBI Motion (Taiwan)
Servo Motors:
6 Sets Of Servo Motors & Drives
Display Screen:
High-definition Screen, Brand: We-con
Stripping Length:
1-10mm (Customizable Beyond Range)
Linear Guides:
HIWIN (Taiwan)
Wire Range:
18AWG-32AWG (8-wire);14AWG-32AWG (5-wire)
Twisting Length:
3-10mm (Customizable Beyond Range)
Cylinders Brand:
Airtac (Taiwan)
Wire Processing Modes:
5-wire Simultaneous Processing For 14AWG-32AWG Cables And 8-wire Processing For 18AWG-32AWG Cables
Adjustable Parameters:
Cutting Length: 20mm To 1000mm, Front & Rear Stripping Length: 1-10mm, Twisting Length: 3-10mm, Tinning Length: 1-10mm
Hourly Output:
5,000 Pieces Per Hour For 5-wire Processing, 8,000 Pieces Per Hour For 8-wire Processing
Wire Compatibility:
18AWG-32AWG (8-wire);14AWG-32AWG (5-wire)
Highlight:
High Capacity Automatic Soldering Machine
, Automatic Soldering Machine Servo Drive
, Servo Drive Wire Crimping Machine
